AA Battery 3.6V Primary Lithium Battery Er14505 Er14505m AA Industrial Battery

Technical specifications:



Battery Technology

Lithium thionyl chloride / LiSOCL2

Battery structure

High capacity type

Nominal Voltage

3.6V

Nominal Capacity

2700mAh

Open circuit voltage

3.66V (at +20°C)

Cut off Voltage

2.0V

Max. Constant Current

65mA

Max. Pulse Current

150mA

Operating Temperature

-55°C~+85°C/-67°F~+185°F

Storage Life

≥10 years

Self – Discharge Rate:

<1% per year

External Diameter (Max)

14.5.0mm

External Height (Max)

50.5mm

Weights





Battery Description:


Battery Model: ER14505 Battery Brand: JFCor OEM
Battery Capacity: 2700mAh ( at 0.5mA,under 25℃, 2.0V cut-off) Dimension: 14.5 x 50.5mm
Open Circuit Voltage: ≥3.66V Load Voltage: ≥3.2V
Max continuous current 100mA ( with 25℃, 2.0V cut-off) Max Discharge current 200mA(1s pulse to 3.0V)
Working temperature: -55~+85℃ Storage Life: 10 years
Storage condition: clean, cool (preferably below +20℃, not exceeding +30℃), dry and ventilated
Applications: PLC system,ETC system,Alarm System,Utility Meters, real-time clock,CMOS board memory and backup power, data backup, smart meter, heat meter, electronic measuring instrument, real-time monitoring system, flow meter, tax control machine, GPS tracking

Battery Description:



Battery Model: ER14505 Battery Brand: JFCor OEM

Battery Capacity: 2700mAh ( at 0.5mA,under 25℃, 2.0V cut-off) Dimension: 14.5 x 50.5mm

Open Circuit Voltage: ≥3.66V Load Voltage: ≥3.2V

Max continuous current 100mA ( with 25℃, 2.0V cut-off) Max Discharge current 200mA(1s pulse to 3.0V)

Working temperature: -55~+85℃ Storage Life: 10 years

Storage condition: clean, cool (preferably below +20℃, not exceeding +30℃), dry and ventilated

Applications: PLC system,ETC system,Alarm System,Utility Meters, real-time clock,CMOS board memory and backup power, data backup, smart meter, heat meter, electronic measuring instrument, real-time monitoring system, flow meter, tax control machine, GPS tracking



  • Size: 14.5mmX50.5mm
  • Nominal Voltage: 3.6V
  • Nominal capacity: 2700mAh
  • Model Number: ER14505
